√ Wrapping outer paper and lining inner paper in one machine
√ Iron plate pasting device(Optional)
|
|
Model |
QBFM900 |
QBFM1000 |
|
1 |
Case size(W×L) |
MIN: 140×240mm MAX: 450×900mm |
MIN: 140×240mm MAX: 600×1050mm |
|
2 |
Paper thickness |
100~200g/m2 |
100~200g/m2 |
|
3 |
Cardboard thickness(T) |
1~3mm |
1~3mm |
|
4 |
Min. spine size (S) |
8mm |
8mm |
|
5 |
Side spine size(s) |
25mm |
25mm |
|
6 |
Folded paper size(R) |
10~18mm |
10~18mm |
|
7 |
Cardboard Qty. |
1-6pieces |
1-6pieces |
|
8 |
Precision |
±0.25mm |
±0.5mm |
|
9 |
Production speed |
≦25sheets/min |
≦20sheets/min |
|
10 |
Total Power |
32kw/380v 3phase |
34kw/380v 3phase |
|
11 |
Air supply |
0.6MPa, 0.8m³/min |
0.6MPa, 0.8m³/min |
|
11 |
Machine weight |
8000kg |
9000kg |
|
12 |
Machine dimension (L×W×H) |
L15000×W6000×H1850mm |
L15000×W6000×H1850mm |
Remark:
The maximum and minimum size of the cover, which also depends on the maximum and minimum size of the face paper and the quality of the face paper
The size of the cover will affect the speed of the machine
Production Flow
 |
