√ Intelligent model, Digital adjustment
√ Multiple fold-in(Max. 4 times), Max.100mm
√ HD Camera & Robot Positioning system
Corresponding relationship between parameters：
W+2H-4T≤C(Max)
L+2H-4T≤≤D
(Max)
A(Min)≤W+2H+2T+2R≤A(Max)
B(Min)≤L+2H+2T+2R≤B(Max)
|
|
Model |
RB600A |
RB600B |
|
1 |
Paper size(A×B) |
Min.100×140mm,Max.610×850mm
|
Min.100×140mm,Max.610×850mm
|
|
2 |
Box size(W×L) |
Min.50×100mm,Max.400×600mm
|
Min. 50×100mm,Max.400×600mm
|
|
3 |
Paper thickness |
100-300g/㎡ |
100-300g/㎡ |
|
4 |
Cardboard thickness(T) |
0.8~3mm |
0.8~3mm |
|
5 |
Box height(H) |
12-150mm |
12-120mm |
|
6 |
Fold-in paper size(R) |
10-100mm |
10-100mm |
|
7 |
Paper ear size |
10-100mm |
10-100mm |
|
8 |
Precision |
±0.10mm |
±0.10mm |
|
9 |
Speed |
≦30pcs/min |
≦30pcs/min |
|
10 |
Paper Stack Height |
380mm |
380mm |
|
11 |
Board Stack Height |
1100mm |
1100mm |
|
12 |
Motor power |
20kw/380v 3phase |
20kw/380v 3phase |
|
13 |
Heater power |
10kw |
10kw |
|
14 |
Machine weight |
5500kg |
5500kg |
|
15 |
Machine dimension(L×W×H) |
L6360*W5000*H3260mm |
L6360*W5000*H3260mm |
